Switch your cross-platform CI to GitHub Actions in 5 minutes

If you maintain an open source project that’s hosted on GitHub, and you’re frustrated by one or more of your current continuous integration (CI) providers, good news: GitHub Actions is a free CI service that supports running tests and other tasks on macOS, Windows, and Linux.

Note that many runtimes are supported by GitHub Actions. This post includes some Node.JS-specific tips.

What’s wrong with GitHub’s docs? đź”—

GitHub’s quickstart and setup docs are a good start for building and testing against the currently supported versions of Node.JS, but if your code has any OS-specific code, these docs don’t tell you how to set up cross-platform builds, and sometimes just knowing what to search for is the biggest stumbling block.

Setting up cross-platform, cross-version builds is easy, though:

Add a new workflow đź”—

Either click the GitHub Actions tab, and click the “New workflow” button:

GitHub Actions tab

GitHub Actions tab

Or, if you’d rather do it manually, edit a new file called .github/workflows/node.js.yml from the base of your project repository.

Then replace the contents of the file with this:

name: Node.js CI
on:
  push:
    branches: [master]
  pull_request:
    branches: [master]
jobs:
  build:
    runs-on: ${{ matrix.os }}
    strategy:
      matrix:
        os: [ubuntu-latest, macos-latest, windows-latest]
        node-version: [10.x, 12.x, 14.x, 15.x]
    steps:
      - uses: actions/checkout@v2
      - name: Use Node.js ${{ matrix.node-version }}
        uses: actions/setup-node@v1
        with:
          node-version: ${{ matrix.node-version }}
      - run: npm ci
      - run: npm test

Note that this assumes you’re using npm and have a package-lock.json. If you’re a yarn user, check out Tip #2.

There’s a bunch going on there, but the magick bits to grok are the strategy.matrix:, runs-on:, and with: keys.

As soon as you commit this and push to GitHub, you should see a build summary show up in your Actions tab:

GitHub Actions build summary

GitHub Actions build summary

You’ll see that the build matrix will include every combination of os and node-version specified in jobs.build.strategy.matrix, which in this case, was 12 different builds.

Tip 1: Customizing the build matrix đź”—

GitHub’s jobs.<job_id>.strategy.matrix reference describes how to include or exclude specific OSes and/or Node versions in your build matrix.

Tip 2: How to use yarn instead of npm đź”—

GitHub’s own runners actually install yarn by default, so (almost) all that you need to do is switch out npm for yarn in your workflow.

If you’re not aware, npm ci does the following:

  1. Recursively deletes the node_modules directory
  2. Runs npm install, but only uses the exact versions specified in the package-lock.json. If package-lock.json is missing, npm ci will fail.

If you’re using yarn (and not using Windows), you can simulate this by adding the following scripts to your package.json:

{
  ...
  "scripts": {
    ...
    "preci": "rm -rf node_modules",
    "ci": "yarn install --frozen-lockfile"
    ...
  }
}

Note that this preci script won’t work if you’re building on Windows. For cross-platform modules, I’m just cheating and skipping over the node_modules cleanup step.

Tip 3: Add or replace your CI build badge đź”—

From the Actions tab, click a build summary, and in the upper right, click …, and then click “Create status badge.”

If you’re building a badge for your README, you want to pick your release branch (so, main or master).

Unfortunately, the markdown that gets displayed is just the image, so if you paste the markdown into your README.md, and someone clicks the build badge, it navigates to the badge image, not the build (!!).

It’s up to you to add a proper link to the build badge: wrap the markdown from the “Create status badge” tool with square brackets, and then add a reasonable destination link, in parenthesis, right after the square brackets.

You’ll end up with something like this:

[![CI build](https://github.com/.../badge.svg)](https://github.com/.../actions)

All together now đź”—

Here’s a commit that

  • switches to GitHub Actions,
  • removes the other CI build configurations,
  • updates the build badge in the README.md, and
  • adds a yarn ci job (without the preci step)

My prior CI for this build matrix could take 30 minutes or more to complete, and required using two different services.

GitHub Actions completes this same matrix in only 6 minutes: ✨ Kudos, GitHub! ✨
