PhotoStructure for Docker

These are instructions for advanced users, wanting to run PhotoStructure for Servers via Docker.

Background reading #

• You should read the pros and cons of both Docker and Node editions before continuing.

• Docker-compose may be easier to use than these instructions, which use docker directly, because:

  • upgrades are automatic
  • adding and removing volumes to scan into your library is easy

  The downside is that it’s one more software package that you need to install, and it may not be available on your host machine. The instructions for docker-compose are here.

• If you want imported volumes in your library to be portable across machines, please read what’s a “volume?” (hint: skip to the last section and create .uuid files for all the volumes you import).

System requirements #

The docker images run under linux x64 Docker hosts.

PhotoStructure containers require at least 2GB of RAM during imports. You’ll see ENOMEM errors if you run within a 1GB container. PhotoStructure imports run faster when more RAM and more CPU are allocated to the container.

The docker image is built on a recent CPU with SSE4 and AVX extensions: CPUs that are less than a decade old should work fine, but if your server is running an older processor (like an AMD Phenom II), the image may not spin up.

Install Docker #

Follow these instructions for docker. If you’re on Ubuntu, follow these steps.

Note you need to use either Docker or Docker Compose: don’t use both simultaneously.

Docker volume setup #

PhotoStructure writes into 4 directories that must be mounted via docker volumes.

The following examples set up PhotoStructure to scan both a mounted external hard drive at /mnt/Photos backup and all files found in $HOME/Pictures. You’ll want to edit these examples to be relevant to your setup.

/ps/library #

This is where your PhotoStructure Library will be stored. It must be readable and writable by the PhotoStructure container, and have sufficient free space.

/ps/tmp #

This is PhotoStructure’s “scratch” directory.

• /ps/tmp must be on a local disk.
• This volume should have at least 16-32 GB free.
• If you’ve got an SSD, use that: this directory will see a lot of reads and writes.
• If you can pick (or create) a volume that doesn’t have data integrity protection, on-the-fly compression, or on-the-fly file de-duplication. This will make imports faster as well as reduce system load.
• PhotoStructure automatically prunes old and unused files from the scratch directory: it shouldn’t take much space unless an import is running.

/ps/config #

This is where PhotoStructure stores system settings.

/ps/logs #

This is where PhotoStructure stores logfiles. Normally PhotoStructure should be mostly quiet, unless you “send recent logs,” or set PS_LOG_LEVEL to something like info.

PhotoStructure deletes logfiles older than 1 week automatically.

Directories to import #

• To add directories you want to import into your PhotoStructure library, simply add them as bind volumes to your container. The following example configurations include a couple examples.

• If you would like to ensure that PhotoStructure doesn’t change anything in the directories you import, you can mount these volumes read-only, with 2 caveats:

  • You will need to drop a .uuid file in the root of these volumes if you want your library to be portable.

  • This will prevent PhotoStructure from being able to write sidecars next to your originals to save metadata changes you make from within the UI.

Directories to omit #

PhotoStructure will import all mounted directories recursively. PhotoStructure respects NoMedia files, and will exclude those directories from being imported. (learn more)

Advanced settings #

PhotoStructure has a bunch of settings that are only configurable outside of the PhotoStructure UI.

Docker users may find it’s easiest to use environment variables to override settings. Read more about PhotoStructure’s use of environment variables.

Library ownership #

Dockerized applications run as root by default. This results in the files in your library as being owned by root.

Running PhotoStructure as a non-root user is more secure.

As of v1.0, PhotoStructure has adopted linuxserver-style PUID/PGID (rather than Docker’s --user option). Read more about this in the forum.

The user specified by PUID/PGID needs to be able to read and write to /ps/library, /ps/tmp, /ps/config, and /ps/logs (and read from any bind mounts that contain photos and videos).

Note that PhotoStructure’s docker-entrypoint.sh script will try to chown -R the bind mounts of these directories to your PUID/PGID. Disable these chown calls by setting PS_NO_PUID_CHOWN=1.

Networking setup #

• The PS_HTTP_PORT environment variable defaults to 1787 but can be changed to a different port to suit.

• If you set up a reverse HTTPS proxy via nginx and find that dynamic updates (like the progress status) aren’t showing up, add this to your nginx config:

proxy_http_version 1.1;
proxy_set_header Connection "";

Example Docker setup #

This bash shell script can be saved to make future upgrades easier. See the docker documentation for more details.

#!/bin/bash

# Howdy, and welcome to PhotoStructure!

# Please review every "CHANGE THIS LINE" below.

# For more details, check out
# <https://photostructure.com/server/photostructure-for-docker/>

PSLIBRARY="$HOME/PhotoStructure" # < CHANGE THIS LINE
mkdir -p "$PSLIBRARY"

# This must be a fast, local disk (preferably an SSD) with many gigabytes free.
# It doesn't have to be in /tmp.
PSTMP="/tmp/ps-$USER"
mkdir -p -m 0700 "$PSTMP"

# This directory stores your "system settings". This directory must not be
# the same as the one used by PhotoStructure for Desktops.
PSCONFIG="$HOME/.config/PhotoStructure-docker"
mkdir -p "$PSCONFIG"

# This directory stores PhotoStructure logfiles.
PSLOGS="$HOME/.config/PhotoStructure/logs"
mkdir -p "$PSLOGS"

# TZ is only used as a backstop.
# Using `tzselect` might be helpful if you don't have TZ set.
TZ=${TZ:-$(cat /etc/timezone)}

# The userid to run PhotoStructure as:
PUID=$(id -u) # < "id -u" will run PhotoStructure as the current user's userid.

# The groupid to run PhotoStructure as:
PGID=$(id -g) # < "id -g" will run PhotoStructure as the current user's groupid.

docker run \
  --name photostructure \
  --detach \
  --restart on-failure `# < optional: starts PhotoStructure on boot.` \
  --stop-timeout 120 `# < gives PhotoStructure 2 minutes to shut down cleanly.` \
  --publish 1787:1787 \
  -e TZ="$TZ" \
  -e PUID="$PUID" \
  -e PGID="$PGID" \
  -v "$PSLIBRARY":/ps/library \
  -v "$PSTMP":/ps/tmp \
  -v "$PSCONFIG":/ps/config \
  -v "$PSLOGS":/ps/logs \
  -v "$HOME"/Pictures:/pictures/ `# < CHANGE THIS LINE` \
  photostructure/server:stable

Note that :alpha, :beta, and :stable releases are available: read the forum for details.

In case of error #

If the PhotoStructure doesn’t spin up successfully, try replacing the --detach line with these lines:

 -e PS_LOG_LEVEL=info \
 -e PS_TAIL_LOGS=1

This runs PhotoStructure in --verbose mode. Note that this can be pretty chatty, but good for debugging why PhotoStructure is grumpy. Use PS_LOG_LEVEL=warn for less output, and PS_LOG_LEVEL=debug for more output.

Still stuck? Hop onto the forum or discord and we’ll help diagnose what’s amiss.

Once you’ve fixed the issue, replace these lines back to --detach.

Welcome to PhotoStructure! #

Open http://localhost:1787 in a browser to complete installation. Firefox, Chrome, and Safari are supported.

While you wait for your import to complete, check out these getting-started tips!

How to stop PhotoStructure #

docker stop photostructure

(replace photostructure with the name of your PhotoStructure docker container)

If you’re wondering why it’s taking a while to shut down, this is why.

How to restart PhotoStructure #

docker start photostructure

How to upgrade PhotoStructure #

Automatic upgrades via Watchtower (recommended) #

If you don’t mind all of your Docker containers to be upgraded automatically, use Watchtower:

docker run -d \
    --name watchtower \
    -v /var/run/docker.sock:/var/run/docker.sock \
    containrrr/watchtower

If you only want your PhotoStructure container to be upgraded automatically, refer to the Watchtower documentation, and how the watchtower container is set up with docker-compose.

Manual upgrade process #

Step 1: Pull the new image #

docker pull photostructure/server:stable

Step 2: Shut down the outdated container #

Select “Shutdown” from the nav menu within the PhotoStructure, or run:

docker stop -t 60 photostructure

Step 3: Rename the outdated container #

docker rename photostructure photostructure_old

Step 4: Start a new container #

docker run \
  --name photostructure \
  --volumes-from photostructure_old \
  `# <copy and paste all the non-volume options you set in step 3, like --user, --expose and -e >`
  photostructure/server

Step 5: Remove the outdated container #

docker rm photostructure_old

Uninstalling PhotoStructure #

1. docker rm --force photostructure
2. As you see fit, remove your LIBRARY, CONFIG, LOG, and TMP directories, but take care not to delete photos and videos you want to keep! If you want to keep the originals in your library, but remove PhotoStructure’s preview images and videos, you can delete the $LIBRARY/.photostructure/previews directory.

Synology docker instructions #

PhotoStructure’s docker image runs happily on intel x64 compatible Synology NAS devices. First install the Docker package via Main Menu > Package Center.

Install on Synology #

Unfortunately, Synology DSM’s Docker interface doesn’t support running containers with --user. This results in your library files being owned by root. It also is less secure to run PhotoStructure as root (even within a Docker container).

Because of these two issues, we recommend setting up the docker container via ssh rather than via the pointy-clicky Synology DSM interface.

Via ssh #

1. Enable ssh on your NAS
2. Set up the above instructions, but change docker run to sudo docker run.

Via Synology DSM #

1. Click Main Menu > Docker
2. Click the Image tab
3. Click Add > Add from URL
4. Enter https://hub.docker.com/r/photostructure/server
5. Pick latest
6. Wait for the image to download (it’s 300MB, it may take a minute). You’ll see a system notification when it’s done.
7. Click Launch
8. Do not select high privilege. You can select resource limitation, but give PhotoStructure at least 2GB.
9. Click Advanced Settings.
10. You may want to enable auto-start under the Advanced Settings tab.
11. Click the Volume tab. Read about the required volumes, and then add entries for
    • /ps/library
    • /ps/tmp
    • /ps/logs
    • /ps/config
    • and any existing directories you want to import into your library.
12. Configure the network port as you’d like it. You can just map port 1787 directly.
13. Click the Network tab, select “bridge”, click “Manage”, click “Add”, then select “PhotoStructure”.
14. Launch the new container by clicking the power switch to the right, and wait for it to start successfully. If it fails, check under the Log tab. Email us if you need help!

Extra credit: if you click on the Container tab, double-click photostructure, and then click the Terminal tab, you can type --status (and hit return) to have PhotoStructure run health checks. (You can also run --pause, --resume, and --exit).

Upgrade on Synology #

Consider using Watchtower, which will upgrade all your docker images automatically: just ssh into your NAS, and run this:

sudo docker run -d --name watchtower -v /var/run/docker.sock:/var/run/docker.sock containrrr/watchtower

(Click “remove container” in the DSM Docker interface to uninstall watchtower).

If you’d rather upgrade manually, it’s a simple 16 step process:

1. Click Main Menu > Docker
2. Click the Container tab
3. Click your PhotoStructure container to select it
4. Click Settings > Export
5. Select Export container settings (you don’t need to store the container contents).
6. The export should be a small JSON file. Store it locally or on your NAS.
7. With your PhotoStructure container still selected, make sure it isn’t running. If it is, select Action > Stop.
8. Click Action > Delete. (this is scary, but as long as you correctly mounted /ps/library, your library will be on your NAS, not inside this container).
9. Click the Image tab
10. Click Add > Add from URL
11. Enter https://hub.docker.com/r/photostructure/server
12. Pick latest
13. Wait for the image to download (it’s 300MB, it may take a minute). You’ll see a system notification when it’s done.
14. Return to the Container tab, and click Settings > Import
15. Import the JSON file you exported in step 6.
16. Launch the new container by clicking the power switch to the right

QNAP docker instructions #

QNAP’s docker support is a bit persnickety as well.

First, open Container Station, click the “Create” tab on the left, then click " ＋ Create Application" in the upper right:

At least as of November 2020, QNAP uses a version of docker-compose from the mid-17th century, which means the docker-compose recipe has to be downgraded to version 3.0: the main result of this is that bind-mount volumes must be formated as - $src:$dest, as the below example.

The other issue is that it seems that the user argument to services doesn’t work correctly: (or at least it didn’t work on my QNAP correctly). The impact of omitting the user argument is that the library and contents will be owned by root.

So, copy and paste this into the YAML text area, and then make sure you edit every line that says CHANGE THIS LINE.:

version: "3"
services:
  photostructure:
    image: photostructure/server:stable
    container_name: photostructure
    restart: on-failure
    stop_grace_period: 2m

    volumes:
      # This is where your PhotoStructure Library will be stored.
      # It must be readable, writable, and have sufficient free space.
      # If it is a remote volume, uncomment the PS_FORCE_LOCAL_DB_REPLICA
      # environment line below. It needs to already exist!
      # (use mkdir -p as the user that runs PhotoStructure)

      - /share/homes/PhotoStructure:/ps/library # < CHANGE THIS LINE

      # This must be fast, local disk with many gigabytes free.
      # PhotoStructure will use this directory for file caching
      # and for storing a temporary database replica when your
      # library is on a remote volume.

      - /tmp/photostructure-tmp:/ps/tmp

      # This directory stores your "system settings". It needs to already exist!
      # (use mkdir -p as the user that runs PhotoStructure)

      - /share/homes/user/.photostructure:/ps/config # < CHANGE THIS LINE

      # This directory stores PhotoStructure logfiles. It needs to already exist!
      # (use mkdir -p as the user that runs PhotoStructure)

      - /share/homes/user/.photostructure-logs:/ps/logs # < CHANGE THIS LINE

      # Example additional directories to import into your library.
      # Add as many as you'd like.

      # You can set the mount point to anything like /media, or /pictures, ...
      # (the name doesn't matter, as long as it is unique,
      # and not in a system directory, like /usr/lib)

      - /share/homes/path/to/photos:/pictures # < CHANGE THIS LINE

      # Add more lines like the one above to scan additional directories.

    ports:
      - 1787:1787/tcp

    environment:
      - "PS_IS_DOCKER=1"
      - "PUID=1000" # < CHANGE THIS LINE to match the userid you want PhotoStructure to run under
      - "PGID=1000" # < CHANGE THIS LINE to match the groupid you want PhotoStructure to run under

    labels:
      # See https://containrrr.dev/watchtower/container-selection/
      - "com.centurylinklabs.watchtower.enable=true"

  watchtower:
    image: containrrr/watchtower
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock
    # Check for updates every couple hours: (3h * 60m * 60s)
    command: --interval 10800
    environment:
      - "WATCHTOWER_LABEL_ENABLE=true"

For the Application name:, use lower-case letters: photostructure works.

Then click “Validate YAML”, and then click “Create”.

Your NAS will then download the images and start the new containers. Once it’s done, click the Containers tab, then click the black triangle by photostructure. You should see something like this:

Click the awesomely-named “photostructure_photostructure_1” link to view the console and other information, including a clickable URL to view your PhotoStructure library.

Edit history #

January 3 3, 2022 #

• Updated the shell script to include a shebang and more comments around TZ, PUID, and PGID.

August 22, 2021 #

• Make all image names use photostructure/server:info

• Add container_name to QNAP’s docker-compose.yml

August 12, 2021 #

• Replace --user references with v1.0’s PUID/PGID

November 17, 2020 #

• Added QNAP instructions

September 22, 2020 #

• Switched to --restart on-failure
• Added --stop-timeout 120

August 7, 2020 #

• Set up --user instructions
• Normal users don’t have read/write to docker volumes, so /ps/log and /ps/cache defaults are bind mounts in the example now.

August 4, 2020 #

• Added more detail about the different volumes
• Removed --init from the docker run command, as v0.8.3 doesn’t require it anymore
• Added section for docker on Synology
• Pulled docker-compose instructions into new doc

July 31, 2020 #

• Systemd start-on-boot configurations were replaced with docker’s built-in restart: unless-stopped functionality.
• Added config fix for https reverse proxy issues with Server-side events.
• Clarified when .uuid files were needed (only for imported volumes, not the library itself).

July 20, 2020 #

• If you used versions prior to 0.8, these instructions have changed. We simplified the instructions to be vanilla Docker,although you’re free to use docker-compose if you prefer.

• Server
• Docs

Hi! I’m Matthew, the author of PhotoStructure. I’m a dad, amateur photographer, and author of open source, adtech, fintech, and edtech software since the turn of the millennium. He/him. I am building a self-hosted, safe, and fast new home for all your photos and videos.
Your memories deserve PhotoStructure. Try it out for free!
